Crosby Straightpoint Wireless Loadshackles

Crosby’s wireless loadshackles are available in capacities from 3.25-400 tonnes and two versions: a long-range 2.4 Ghz version with a range of 3,280 feet, or a Bluetooth output that can be connected to any iOS or Android smartphone with ranges of up to 328 feet.

SPECIFICATIONS

Mechanical or Digital
Digital

Capacity
7,150 lb to 0-880,000 lbs

Unit of Measure
lb. & ton

Resolution
Refer to spec sheet

Memory Storage
Via HHP App

Data Export
Via HHP App

Operating Range
14F to 122 F (-10 C to + 50 C)

Recalibration
Every 12 months

Crosby Straightpoint Wireless Loadshackles

Proof Load
150%

Modes
Live & Peak modes with audiable alarm

Capture Rate
2.4 GHz wireless

Accuracy
± 1% of full scale

Display
Via HPP App

Environmental
Suitable for continuous outdoor use IP67.NEMA6

Approvals
Complies with ASME B30.26

Advantages of wireless loadshackles

Industry-leading durability

Each loadshackle is proof-tested and equipped with a hard aluminum electronics enclosure, containing an internal chassis providing IP67 or NEMA6 environmental protection even if you’re missing the battery cover plate. This ensures that your loadshackles can be reliably used even in the harshest environments, and will last for years under any conditions.

Advanced wireless functionality and accessories

The wireless loadshackles are supplied with an update range of 3Hz and can be configured to run at speeds of up to 200Hz if required. They can also be combined with Straightpoint’s software package to allow the operator to perform load tests at a distance and generate real-time test certificates.

Resilient circuitry

The wireless loadshackles include circuitry designed to protect the unit from damage associated with incorrectly installed batteries. This innovative design also extends battery life and uses easily sourced alkaline batteries to remove the need for battery pack charging, failure, and replacement.
