Find the right Load Limit Switch
Load limit switches are crucial to promoting personnel and worksite safety, and can be configured to sound alarms when cables reach critical tension levels.
Dillon Load Limit Switches at a glance
 Dillon Cranegard |  Dillon DynaSwitch |  MSI Clamp on Load cell |
|
|---|---|---|---|
| Available Capacities | CGS-1: 2,500 lb | 1,250 kg CGS-2: 5,000 lb | 2,500 kg CGS-3: 10,000 lb | 5,000 kg CGS-4: 20,000 lb | 10,000 kg | DSW-1: 100 lb | 50 kg DSW-2: 1,000 lb | 500 kg DSW-3: 2,000 lb | 1,000 kg DSW-4: 5,000 lb | 2,500 kg DSW-5: 10,000 lb | 5,000 kgDSW-6: 25,000 lb | 12,500 kg DSW-7: 50,000 lb | 25,000 kg | Not applicable based on cable diameter |
| Method of installation | ClampOn | Inline | ClampOn |
| Safety Factor | 2:1 Ultimate Safety Factor (Metric capacities 1.8:1) | 5:1 Ultimate Safety Factor (Metric capacities 4.5:1) | 4340 Steel, Zinc Plated |
| Cable diameters | 3/8” – 1¼” | Not Applicable | Up to 3/4" |
| Features | Up to 4 switches for slack and overload Switches can be wired to trigger anything from a warning alarm to complete system shutdown Slack setpoint as low as 100 lb (50 kg) dependent on capacity Setpoints can be adjusted in the field | Up to 4 switches for slack and overload Switches can be wired to trigger anything from a warning alarm to complete system shutdown Slack setpoint as low as 15 lb (7.5 kg) dependent on capacity Setpoints can be adjusted in the field | Multiple Load Limit functions when paired with Transmitter and Digital Indicator "Can trigger anything from a warning alarm to complete system shutdown" No minimum setpoint Setpoints can be adjusted in the field |
| REQUEST QUOTE LEARN MORE | REQUEST QUOTE LEARN MORE | REQUEST QUOTE LEARN MORE |
|
Dillon Load Limit Switches at a glance
| Available Capacities | Method of installation | Safety Factor | Cable diameters | Features | ||
|---|---|---|---|---|---|---|
| Dillon Cranegard | CGS-1: 2,500 lb | 1,250 kg CGS-2: 5,000 lb | 2,500 kg CGS-3: 10,000 lb | 5,000 kg CGS-4: 20,000 lb | 10,000 kg | ClampOn | 2:1 Ultimate Safety Factor (Metric capacities 1.8:1) | 3/8” – 1¼” | Up to 4 switches for slack and overload Switches can be wired to trigger anything from a warning alarm to complete system shutdown Slack setpoint as low as 100 lb (50 kg) dependent on capacity Setpoints can be adjusted in the field | REQUEST QUOTE LEARN MORE |
| Dillon DynaSwitch | DSW-1: 100 lb | 50 kg DSW-2: 1,000 lb | 500 kg DSW-3: 2,000 lb | 1,000 kg DSW-4: 5,000 lb | 2,500 kg DSW-5: 10,000 lb | 5,000 kgDSW-6: 25,000 lb | 12,500 kg DSW-7: 50,000 lb | 25,000 kg | Inline | 5:1 Ultimate Safety Factor (Metric capacities 4.5:1) | Not Applicable | Up to 4 switches for slack and overload Switches can be wired to trigger anything from a warning alarm to complete system shutdown Slack setpoint as low as 15 lb (7.5 kg) dependent on capacity Setpoints can be adjusted in the field | REQUEST QUOTE LEARN MORE |
| MSI Clamp on Load cell | Not applicable based on cable diameter | ClampOn | 4340 Steel, Zinc Plated | Up to 3/4" | Multiple Load Limit functions when paired with Transmitter and Digital Indicator "Can trigger anything from a warning alarm to complete system shutdown" No minimum setpoint Setpoints can be adjusted in the field | REQUEST QUOTE LEARN MORE |
