Dillon DynaSwitch Load Limit Switches
The Dillon DynaSwitch is a reliable, cost-effective way to control force and prevent overloads. It can be used on cranes, hoists, and elevators to shut off power when an overload condition exists, or warn workers of an impending overload. The DynaSwitch system is built with a force beam that operates in either tension or compression, and can accommodate up to four switches which can be set to trigger under a variety of conditions.
SPECIFICATIONS
Available Capacities
DSW-1: 100 lb | 50 kg
DSW-2: 1,000 lb | 500 kg
DSW-3: 2,000 lb | 1,000 kg
DSW-4: 5,000 lb | 2,500 kg
DSW-5: 10,000 lb | 5,000 kg
DSW-6: 25,000 lb | 12,500 kg
DSW-7: 50,000 lb | 25,000 kg
Method of installation
Inline
Safety Factor
5:1 Ultimate Safety Factor
(Metric capacities 4.5:1)
Cable diameters
Not Applicable
Features
Up to 4 switches for slack and overload
Switches can be wired to trigger anything from a warning alarm to complete system shutdown
Slack setpoint as low as 15 lb (7.5 kg) dependent on capacity
Setpoints can be adjusted in the field
Resources
1-4 microswitches can be installed depending on the number of set points your application requires.
Yes, when you request the load setting(s) to be set at the factory, a Certificate of Calibration traceable to NIST is included.
No, load settings are included in the price of the DynaSwitch.
Yes, providing you can apply a known load equal to the desired load setting. Instructions on how to set load settings in the field are provided in the user manual.
Yes, you can have two microswitches installed: one set for increasing load and one for decreasing load.
We recommend calibration every 12 months.
You can send the DynaSwitches to the following address:
Dillon/Quality Plus, Inc.
214 E. Kansas St. Ste 101
Liberty, MO 64068
We ask that you complete and include the RMA Form located under the “Calibration and Repair” portion of our website with the shipment.
On new units we offer a 12 month limited warranty on parts and workmanship. On repaired units we offer a 30 day warranty.
