Find the right dynamometer
Dillon and Crosby Straightpoint dynamometers (also called Dillon load cells and Crosby Straightpoint load cells) allow your team to quickly and easily measure tension on a line or suspended load.
Dillon Dynamometers and Crosby Straightpoint Dynamometers at a glance
 AP Dynamometer |  EDjunior Dynamometer |  Wireless EDXtreme Dynamometer |  Wireless EDXtreme Blue Dynamometer |  Bluetooth Radiolink Plus Dynamometer |  Bluetooth Bluelink Dynamometer |  Wireless Load Shackles | |
|---|---|---|---|---|---|---|---|
| Brand | Dillon | Dillon | Dillon | Dillon | Crosby Straightpoint | Crosby Straightpoint | Crosby Straightpoint |
| Mechanical or Digital | Mechanical | Digital | Digital | Digital | Digital | Digital | Digital |
| Capacity | 500 lb to 50,000 lb | 2,500 lb to 25,000 lb | 2,500 lb to 550,000 lb | 2,500 lb to 25,000 lb | 2,200 lb to 1,100,000 lb | 0-14,300 lbs | 7,150 lb to 0-880,000 lbs |
| Unit of Measure | lbf or kgf | lbf, kgf & Newtons | lbf, kgf & Newtons | lbf, kgf & Newtons | lbs, kgs, ton & kN | lbs. ton, kg & kN | lb. & ton |
| Resolution | Refer to spec sheet | 1/1000 resolution | Low / med / high (5000 resolutions) | Low / med / high (5000 resolutions) | Refer to spec sheet | 2 lbs | Refer to spec sheet |
| Memory Storage | N/A | N/A | Up to 255 logs | Up to 255 logs | Via HHP App | Via HHP App | Via HHP App |
| Data Export | N/A | N/A | RS232 | Bluetooth to Dillon EDX mobile app | Via HHP App | Via HHP App | Via HHP App |
| Operating Range | -50º F to 140º F | -4° F to 158° F (-20° C to 70° C) | -4° F to 158° F (-20° C to 70° C) | -4° F to 158° F (-20° C to 70° C) | 14F to 122 F (-10 C to + 50 C) | 14F to 122F (-10C to +50C) | 14F to 122F (-10C to +50C) |
| Recalibration | Every 12 months | Every 12 months | Every 12 months | Every 12 months | Every 12 months | Every 12 months | Every 12 months |
| Proof Load | 150% | 150% | 150% | 150% | 150% | 150% | 150% |
| Modes | N/A | Live & Peak display modes | Seven display modes including live & peak | Seven display modes including live & peak | Live & Peak modes with audiable alarm | Live & Peak modes with audiable alarm | Live & Peak modes with audiable alarm |
| Capture Rate | N/A | 10Hz | 10Hz, 100Hz & 1000Hz | 10Hz, 100Hz & 1000Hz | 3 Hz | 3 Hz | 2.4 GHz wireless |
| Accuracy | +/- 0.5% of instrument capacity | ± 0.2% of instrument capacity | ± 0.1% of instrument capacity | ± 0.1% of instrument capacity | 0.1% of instrument Capacity | 0.2% of instrument capacity | ± 1% of full scale |
| Display | 5″ and 10″ dial face | Dot-graphic LCD display supports full text and 1” high digits | Dot-graphic LCD display supports full text and 1” high digits | Dot-graphic LCD display supports full text and 1” high digits | Via HPP App | Via HHP App | Via HHP App |
| Environmental | Suitable for continuous outdoor use | Suitable for continuous outdoor use | Suitable for continuous outdoor use | IP68 Suitable for continuous outdoor use | Suitable for continuous outdoor use | Suitable for continuous outdoor use IP67.NEMA6 | Suitable for continuous outdoor use IP67.NEMA6 |
| Approvals | CE / ASME B30.26 (up to 20,000 lbs.) | CE | CE | CE | Complies with ASME B30.26 | FCC, IC, Japan & Korea Certifiication | Complies with ASME B30.26 |
| REQUEST QUOTE LEARN MORE | REQUEST QUOTE LEARN MORE | REQUEST QUOTE LEARN MORE | REQUEST QUOTE LEARN MORE | REQUEST QUOTE LEARN MORE | REQUEST QUOTE LEARN MORE | REQUEST QUOTE LEARN MORE |
Dillon Dynamometers and Crosby Straightpoint Dynamometers at a glance
| Brand | Mechanical or Digital | Capacity | Unit of Measure | Resolution | Memory Storage | Data Export | Operating Range | Recalibration | Proof Load | Modes | Capture Rate | Accuracy | Display | Environmental | Approvals | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| AP Dynamometer | Dillon | Mechanical | 500 lb to 50,000 lb | lbf or kgf | Refer to spec sheet | N/A | N/A | -50º F to 140º F | Every 12 months | 150% | N/A | N/A | +/- 0.5% of instrument capacity | 5″ and 10″ dial face | Suitable for continuous outdoor use | CE / ASME B30.26 (up to 20,000 lbs.) | REQUEST QUOTE LEARN MORE |
| EDjunior Dynamometer | Dillon | Digital | 2,500 lb to 25,000 lb | lbf, kgf & Newtons | 1/1000 resolution | N/A | N/A | -4° F to 158° F (-20° C to 70° C) | Every 12 months | 150% | Live & Peak display modes | 10Hz | ± 0.2% of instrument capacity | Dot-graphic LCD display supports full text and 1” high digits | Suitable for continuous outdoor use | CE | REQUEST QUOTE LEARN MORE |
| Wireless EDXtreme Dynamometer | Dillon | Digital | 2,500 lb to 550,000 lb | lbf, kgf & Newtons | Low / med / high (5000 resolutions) | Up to 255 logs | RS232 | -4° F to 158° F (-20° C to 70° C) | Every 12 months | 150% | Seven display modes including live & peak | 10Hz, 100Hz & 1000Hz | ± 0.1% of instrument capacity | Dot-graphic LCD display supports full text and 1” high digits | Suitable for continuous outdoor use | CE | REQUEST QUOTE LEARN MORE |
| EDXtreme Blue Dynamometer | Dillon | Digital | 2,500 lb to 25,000 lb | lbf, kgf & Newtons | Low / med / high (5000 resolutions) | Up to 255 logs | Bluetooth to Dillon EDX mobile app | -4° F to 158° F (-20° C to 70° C) | Every 12 months | 150% | Seven display modes including live & peak | 10Hz, 100Hz & 1000Hz | ± 0.1% of instrument capacity | Dot-graphic LCD display supports full text and 1” high digits | IP68, Suitable for continuous outdoor use | CE | REQUEST QUOTE LEARN MORE |
| Bluetooth Radiolink Plus Dynamometer | Crosby Straightpoint | Digital | 2,200 lb to 1,100,000 lb | lbs. ton, kg & kN | Refer to spec sheet | Via HHP App | Via HHP App | 14F to 122 F (-10 C to + 50 C) | Every 12 months | 150% | Live & Peak modes with audiable alarm | 3 Hz | 0.1% of instrument Capacity | Via HPP App | Suitable for continuous outdoor use | Complies with ASME B30.26 | REQUEST QUOTE LEARN MORE |
| Bluetooth Bluelink Dynamometer | Crosby Straightpoint | Digital | 0-14,300 lbs | lbs. ton, kg & kN | 2 lbs | Via HHP App | Via HHP App | 14F to 122F (-10C to +50C) | Every 12 months | 150% | Live & Peak modes with audiable alarm | 3 Hz | 0.2% of instrument capacity | Via HHP App | Suitable for continuous outdoor use IP67.NEMA6 | FCC, IC, Japan & Korea Certifiication | REQUEST QUOTE LEARN MORE |
| Wireless Load Shackles | Crosby Straightpoint | Digital | 7,150 lb to 0-880,000 lbs | lb. & ton | Refer to spec sheet | Via HHP App | Via HHP App | 14F to 122F (-10C to +50C) | Every 12 months | 150% | Live & Peak modes with audiable alarm | 2.4 GHz wireless | ± 1% of full scale | Via HHP App | Suitable for continuous outdoor use IP67.NEMA6 | Complies with ASME B30.26 | REQUEST QUOTE LEARN MORE |
